ULTRA HIGH MOLECULAR WEIGHT POLYETHYLENE
Ultra High Molecular WEIGHT Polyethylene (PE-UHMW)
Polyethylene can be polymerized into types with an extremely high molecular weight of up to 10 million g/mol. From a molecular weight of 1 million g/mol, one speaks of ultra-high molecular weight PE (PE-UHMW).
With increasing molecular weight, wear resistance and impact strength in particular improve. Grades with a molecular weight of up to 5 million g/mol are used as standards. Particularly wear-resistant special grades have a molecular weight of 7 to over 9 million g/mol.
Due to the high molecular weight, the material viscosity also increases, so that PE-UHMW can only be processed by compression molding. An injection molding or screw extrusion processing are not possible. Semi-finished products for machining are consequently pressed and thus relatively free of tension.
PE-UHMW shows the most balanced property profile of all polyethylenes and offers a very good impact strength even at temperatures down to minus 200°C. The material has also the best wear resistance of all technical plastics at room temperature. In this context, the types with particularly high molecular weight (> 7 million g/mol) surpass the standard version by another approx. 20%.
Main features
- excellent wear resistance
- high impact strength even at very low temperatures
- heat deflection temperature 40°C
Standard Types
Type |
DIN-Designation |
Description |
Data Sheet
|
FDA |
Ultra Wear® 1000
|
PE-UHMW |
standard quality with approx. 5 Mio. g/mol |
PDF |
PDF |
Ultra Wear® AST |
PE-UHMW AST |
antistatic with approx. 5 Mio. g/mol |
PDF |
- |
Ultra Wear® MD |
PE-UHMW |
magnetic detectable approx. 9 Mio. g/mol |
PDF |
PDF |
Type |
DIN-Designation
|
Description |
Data Sheet
|
FDA |
Ultra Wear® 1000 R |
PE-UHMW R |
from regrind approx. 4,5 Mio g/mol |
PDF |
- |
X-tended Wear® XS |
PE-UHMW |
for dry running approx. 9 Mio g/mol.
|
PDF |
- |
X-tended Wear® DS |
PE-UHMW
|
high wear resistant approx. 9 Mio g/mol. |
PDF |
PDF |
X-tended Wear® XL |
PE-UHMW GB |
glass sphere reinforced approx. 9 Mio g/mol. |
PDF |
- |
X-tended Wear® SP |
PE-UHMW X |
radiation crosslinked approx. 9 Mio g/mol. |
PDF |
- |
Ultra Wear® GS |
PE-UHMW MO |
with MoS2 approx. 9 Mio g/mol. |
PDF |
- |
Ultra Wear® HT |
PE-UHMW HT |
self-extinguishing approx. 9 Mio g/mol. |
PDF |
PDF |
Ultra Wear® V0 |
PE-UHMW FR |
self-extinguishing approx. 5 Mio g/mol. |
PDF |
- |
Ultra Wear® CS |
PE-UHMW C |
antistatic approx. 5 Mio g/mol. |
PDF |
PDF |
Ultra Wear® Öl |
PE-UHMW |
low friction coeff. approx. 9 Mio g/mol. |
PDF |
- |
FDA = suitable for food contact according to FDA
Components made from Ultra Wear® 1000, from Ultra Wear® MD, Ultra Wear® HT, Ultra Wear® CS and Ultra Wear® oil can additionally be supplied with a statement of suitability for contact with foodstuffs in accordance with Regulation (EC) 1935/2004.
For further information on PP, PE-HD or PE-HMW click on the appropriate material group!
Information on the available semi-finished product dimensions is available here!
