TRIBOLOGICALLY MODIFIED PLASTICS
Tribologically modified plastics
There are specially modified plastics for tribological use. By adding graphite (GR), fluorocarbon (TF), carbon fibres (CF), MoS2 (MO) polyolefin waxes or other solid lubricants, the generally good tribological properties of the plastics can be further improved.
In addition to the unfilled standard types, modified plastics in particular are successfully used in tribological applications:
Plastics for highest bearing loads
Type |
Description |
Data Sheet
|
Torlon® 4301 |
high compressive strength, acceptable toughness |
PDF |
Torlon® 4275 |
for high speed at low pressure |
PDF |
Torlon® 4435 |
for extremely high p x v values |
PDF |
Torlon® 4630 |
extremely wear-resistant, for dry running |
PDF |
Torlon® 4645 |
extremely wear-resistant, for lubricated applications |
PDF |
Vespel® SP-21 |
universally applicable at high temperatures |
PDF |
Vespel® SP-211 |
for dry running at low pressure |
PDF |
Vespel® SP-22 |
low thermal expansion, high creep resistance |
PDF |
Vespel® SCP-5050 |
for high wear and temperature requirements |
PDF |
Vespel® SCP-50094 |
for highest temperature requirements |
PDF |
Plastics for high bearing loads
Type |
Description |
Data Sheet
|
Victrex® PEEK FC 30 |
Standard quality for high loads |
PDF |
Ketron® HPV |
with BAM approval for O2 contact |
- |
Ketron® TX |
for food contact - |
- |
Techtron® HPV |
for moderate loads under temperature |
PDF |
Fluorosint® 500 |
best sliding properties, for high temperature |
PDF |
Fluorosint® HPV |
best sliding properties, for food |
PDF |
Plastics for normal bearing loads
Type |
Description |
Data Sheet
|
Nylatron® GS |
good wear resistance, up to diameter 50 mm |
PDF |
Nylatron® GSM |
good wear resistance, from diameter 50 mm |
PDF |
Nylatron® NSM |
for high p x v values |
PDF |
Nylatron® 703XL |
for high p x v values, low stick-slip |
PDF |
Nylatron® M oil |
for relatively fast running applications |
PDF |
Acetron® C-TF |
good recovery, with TF powder |
PDF |
Acetron® H-AF |
extremely low stick-slip tendency, with TF fibres |
PDF |
TECHTRON® HPV |
high wear resistance, low coefficient of friction |
PDF |
Plastics for lowest bearing loads
Type |
Description |
Data Sheet
|
X-tended Wear XS |
reduced coefficient of friction, antistatic |
PDF |
X-tended Wear DS |
for contact with abrasive products (powder etc.) |
PDF |
X-tended Wear XL |
for relatively higher loads |
PDF |
X-tended Wear SP |
wear-resistant due to partial cross-linking |
PDF |
Ultra Wear® GS |
good wear resistance and sliding properties |
PDF |
Ultra Wear® Öl |
low coefficient of friction |
- |
